JBC CA-1QG 120V Solder Feed Station

SKU JBC-CA-1QG

The perfect station for applications requiring a free hand to solder wire, connectors, transformers, or THT components. It uses AP250 Solder Feed Iron, a great tool for repetitive tasks which ensures easy control of the amount of tin dispensed. CA works with the comfortable AP250 and C250 cartridges.

Large Unit Dimensions (inches): 92.3x9.21x10.16
Item Weight: 7.76 lb
(0)No Reviews yet

Details

JBC CA-1QG 120V - Solder Feed station. The CA is a soldering station for intensive jobs which require you have a free hand. It works with the JBC exclusive heating system and the intelligent sleep & hibernation features. Using the menu you can personalize parameters to help manage the soldering process. It incorporates a USB connector to update station software and create graphs. This station includes:

  • Fast and easy configuration of the station thanks to the 7-key keypad.
  • Cartridge Holder to store up to four cartridges, as well as Cartridge Extractor and Cable Collector.
  • Connectivity to JBC Fume Extractor (connector RJ12).

Complete cleaning system with an antisplash membrane to keep the work area clean. Use the integrated wiper to remove excess solder from the tip.

Product Composition:

1 CA Control Unit with AP250 Manual-Feed Soldering Iron
(Cartridge not included)

Specifications:


Weight2.91 kg (6.42 lb)
Size170x176x145 mm
Voltage(AC)120V
FAE / Robot connectorRemote control or FAE Fume Extractor connection
Output Peak Power130W / 23.5V
Temperature selection90-450 ºC / 190-840 ºF
Tip to ground resistance<2 ohms
Tip to ground voltage<2mV RMS
Ambient operating temp.10 to 50 ºC / 50 to 120 ºF
ESD Safe
Diameter of Solder Wire0.8-1 mm (0.03-0.04 in)
USB interface station-PC



The perfect station for applications requiring a free hand to solder wire, connectors, transformers, or THT components

JBC CA-1QG Solder Feed Station

Cartridge Range

C250 Range

Product SDS, TDS, Manuals

Product Dimensions (in): Length

92.3

Width

9.21

Height

10.16

Weight

7.76
